Steel  Pontoon:

1, The main pontoon bridge structure is:
High-Strength steel structure, the welding, hot-dip galvanizing molding, and imports of high-density polyethylene

Olefin material floating box (black) assembled. The high quality solid wood deck on the aisle surface (or solid jade sandalwood)

Flooring) is fixed to the keel by stainless steel screws. Each section of the standard pontoon contains a parquet and a fender

Dedicated hydropower aluminum alloy gussets, flexible joint system according to design requirements.

2, Technical parameters:

- Bearing capacity: 120,150,180 Kg / m2 ± 5%

- Freeboard height: 0,5 m ± 2 cm

- Main structure: hot galvanized steel (channel height 180,100 mm, etc.)

- WPC Decking: Solid WPC Decking

- Float: Foam and counterweight materials are mixed in rotomolding

- Anti-collision strip: special plastic wood profiles
